36v Roj teeb Charger
1.Cov ntsiab lus ntawm 36v roj teeb charger
Lub 36V roj teeb charger yog ib qho yuav tsum muaj rau txhua lub hnub ci off-grid. Qhov no 800W SMCZ1 SERIES CHARGER tuaj yeem siv nrog ntau hom roj teeb, suav nrog cov dej nyab cov kua qaub, AGM, Gel thiab Lithium Ion. Nws nta muaj zog tiv thaiv kev ua haujlwm txhawm rau tiv thaiv lub roj teeb ntawm overcharging lossis luv circuiting. Nrog 93 feem pua kev ua tau zoo koj paub tias koj lub cuab yeej yuav them sai sai thiab nyab xeeb yam tsis muaj nkim lub zog ntawm cov kauj ruam tsis tsim nyog. Cov tsim hauv software kuj ua kom ntseeg tau tias qhov kev them nyiaj nkhaus tau teeb tsa raws li koj lub roj teeb tshwj xeeb kom nws ua kom nws lub neej ntev. Koj tuaj yeem siv lub charger no ntawm qhov kub li ntawm -20 degrees Celsius mus txog 85 degrees Celsius, ua rau nws zoo meej rau txhua tus.
2. Qauv ntawm 36v roj teeb charger
Qauv |
Rated voltage (V)
|
Max them Voltage (V)
| Max tso zis tam sim no (A) | Loj (mm) |
Qhov hnyav (kg) | |||
220v AC ua | 110v AC ua | L | W | H | ||||
SMCZ7-800W Tswv yimTsawg dua los yog sib npaug6A | 24 | 29.2 | 15 | 10 | 190 | 140 | 74.5 | 2.0 |
36 | 43.8 | 15 | 15 | |||||
48 | 54.75 | 15 | 12 | |||||
60 | 84 | 12 | 8 | |||||
72 | 88 | 10 | 6 | |||||
3.Technical yam ntxwv ntawm 36v roj teeb charger
SMCZ7-800W Fully Sealed Charger
Yam khoom | Tsis muaj |
Ac Input Wide Voltage Range | AC90v-264v |
AC Input Frequency Range | 40-70HZ |
Nrog APFC Kev Ua Haujlwm, Lub Zog Muaj Zog | Ntau dua lossis sib npaug rau 0.98 |
Soft Switching Technology, Efficiency | Ntau dua lossis sib npaug li 93 feem pua |
Charge hom | Adjustable Dynamic |
Qib tiv thaiv | IP67 |
Ua haujlwm kub | -40 degree ~ ntxiv rau 60 degree |
Cia Kub | -55 degree ~ ntxiv rau 100 degree |
LED Lub teeb qhia rau kev them nqi | Txuj |
Suab nrov | Tsawg dua lossis sib npaug li 45dB |
Zuag qhia tag nrho | 190 x 140 x 74.5 hli |
Net nyhav | 2 0kg |
Tswv yim | Stand-by Consumption | Tsawg dua lossis sib npaug li 5W |
Main tso zis | Tso zis hom | CV / CC |
Tso zis zog | 800W @ 220VAC Cov | |
CV Qhov tseeb | ± 1 feem pua | |
CC Qhov tseeb | ± 1 feem pua | |
Ripple Voltage Coefficient | 5 feem pua | |
Tsawg Voltage Output | Tso zis hom | Tsis tu ncua Voltage |
Cov zis hluav taws xob | 13.8V | |
Rated Tam sim no | 5A | |
CV Qhov tseeb | ± 2 feem pua | |
Qhov siab tshaj tam sim no | 5.5A±0.5A | |
Tso zis zog | Ntau tshaj lossis sib npaug rau 62.5W | |
Ripple Voltage Coefficient | 1 feem pua | |
Kev sib txuas lus muaj nuj nqi | CAN Kev Sib Txuas Lus | Yog lawm |
Baud Rate | 125Kbps, 250Kbps, 500Kbps | |
Terminal Resistance | N/A |
4. Kev tiv thaiv muaj nuj nqi ntawm 36v roj teeb charger
5. Daim ntawv thov ntawm 36v roj teeb charger
